Useashieldednetworkcable(STP)CAT5orhigher.
-A:viaanEthernetRJ45cablethatisconnectedto
themidspan’sRJ45port(DATAIN).
-B:viaanopticalbrecableattachedtoanSFP
modulethatisconnectedtothemidspan’sSFPslot
(DATAIN).
2.Connectthemidspan(DATAPWROUT)tothecamera’sRJ45
portusinganEthernetRJ45cable.
3.Connectthemidspantoagrounded(earthed)mainspower
outlet(100–240VAC)usingthesuppliedpowercable.
4.VerifythatthemidspanLEDsindicatethecorrectstatuses.
SeeLEDindicatorsonpage13.
