Installationsanleitung AXIbox 11K
EN211103 4
The charging cable must not be kinked, pinched, run over or otherwise damaged.
Keep children away from the charging station.
The car must not be driven during charging.
3 Description oft he product
3.1 Function and intended use
The AXIbox 11K is used for charging electric cars. There is a choice of two modes, which can be set during
installation: In Plug & Play mode, no authentication by the user is necessary. Charging can be started
without unlocking after inserting the charging plug into the car's charging socket. If, on the other hand, the
charging mode with access restriction is selected, the charging process does not start automatically when
the plug is inserted, but must first be authorised by an RFID card at the wallbox or with the App. This
prevents unauthorised use.
3.2 Scope of delivery
The AXIbox 11K is delivered with the following parts:
• 1 x AXIbox 11K housing with electronics and pre-installed charging cable with type 2 plug
• 6 x Screws with associated expansion pipes for wall mounting
• 1 x Seal for sealing the screw connection
• 1 x Cable clamp for fixing the supply cable with associated screws
• 1 x Cable holder
• 5 x Wire end ferrules
• 2 x RFID cards
• 1 x Template for drilling the holes for wall mounting
• 1 x Allen key for opening and closing the housing
3.3 Technical data
