If you have installed Duox in the back
seat you can now move the front seat to a
comfortable position. e back of the child
restraint can, but is not necessary, be in con-
tact with the back of the front seat.
Adjusting the internal harness
Place your child in the car seat. Put your
child’s arms in between the shoulder straps
so that the straps are hanging over the chest
and stomach. Pull the shoulder straps to-
gether and insert the harness tongues into
the crotch buckle. Pull the harness adjust-
ment strap (11). It´s important that you
always pull the harness straight and central
when you tighten the adjustment strap.
is will tighten the harness and the head-
rest will automatically slide down to the
appropriate height. To release the harness,
press the harness adjustment button and
pull both harness straps. Press the red but-
ton on crotch buckle to disengage buckle.
Parking brake on headrest
e headrest on your Duox is
equipped with a parking brake. To activate
the parkingbrake, pull the harness until
the headrest is at desired height, you will
hear a “click” sound from the headrest as
it locks into position then activate the
brake by moving the lever (14) on the
headrest across to the right. Do not pull
up the headrest with the parking brake
activated.
14
12
10
11
