ASSEMBLING THE MACHINE
1. Assembling the vacuum
(1) Nomenclature
Dust bag
Fan cover
(2)Assembly
Open the fan cover, Insert discharging pipe into dust
connect inhale pipe bag from the jaws of the slide
No.1 and No.2 fastener according to the picture
discharging pipe.
Inhale pipe
NO.1
Inhale pipe
NO.2
Discharging
pipe
Lower handle
