ILLUSTRATION AND PARTS DESCRIPTION
12
NVR ON/OFF control switch Drive belt tensioning grub
screw and locking nut
Linisher function with worktable
Three function positions
Linisher function, utilising the
linisher’s guard as a work support
Disc function (A) set at 90˚ degrees
Disc function (B) set at 45˚ degrees
Worktable adjusting Hex bolt
63mm dust extraction outlet
Linisher guard/Workstop, can be used as a work support
when the linisher is in the vertical position
A
B
