Axminster WORKSHOP AW150BDS - Page 21

EXPLODED DIAGRAMSLISTS
21
No Specification Qty
1 Philips screw M5 x 35 2
2 Belt guard 1
3 Hex screw M8 x 35 2
4 Big flat washer M4 x 8 3
5 Screw M12 x 10 2
6 Hex screw M12 x 30 1
7 Hex nut M12 2
8 Spring washer φ12 1
9 Sleeve 1
10 Base 1
11 Capacitor 100uF/250V 1
12 Capacitor clamp 1
13 Spring washer ϕ4 5
14 Phillips screw M6 x 8 3
15 Idler pulley 1
16 Relay 1
17 Screw ST2.9 x 30 1
18 Wire connection box 1
19 Cord clip 1
20 Plug and cord 1
21 Protect plate 1
22 Screw ST4.2 x 10 2
23 Switch KJD20-2 1
24 Belt paper 1
25 Bearing 6001 4
26 Idler roller 1
27 Retainer ring φ12 2
28 Sleeve 2
29 Idler shaft 1
30 Adjustment spring 1
31 Rubber washer 1
32 Flat washer φ6 3
33 Adjustment knob 1
34 Phillips screw +spring
washer
M5 x 25 3
35 Joint lever 1
36 Spring 1
37 Support 1
38 Support cover 1
39 Philips screw M5 x 25 2
40 Pin 5 x 10 1
41 Tension knob 1
42 Sleeve 1
43 Pin 1.6 x 10 1
44 Tension pole 1
45 Phillips screw +tooth
washer+big flat washer
M5 x 16 1
46 Spring washer
φ6
4
47 Philips screw M5X8 3
48 Bearing cap 1
49 Philips screw+flat
washer
M5 x 10 5
50 Hex screw M12 x 20 1
51 Retainer φ6 2
52 Retainer washer M5 2
53 Bolt M4 x 20 2
54 Limiting plate 1
55 Hex screw+flat washer M8 x 16 2
56 Hex screw M8 x 16 1
57 Driving roller 1
58 Philips screw+lock
washer
M5 x 16 left 2
59 Bearing base 1
60 Retainer M5 x 20 3
61 Philips screw M10 x 16 1
62 Flat washer φ5 1
63 Table 1
64 Mitre gauge 1
65 Spring washer φ5 1
66 Philips Screw M5 x 10 1
67 Support rod 1
68 Table damping set 1
