EXPLODED DIAGRAMSLISTS
22
69 Hex nut M5 1
70 Knob 1
71 Hex nut M6 1
72 Table pointer 1
73 Table support rod 1
74 Connect block 1
75 Belt 1
76 Motor arbor wheel 1
77 Hex bolt M6 x 122 4
78 Motor rod 1
79 End cap 2
80 Bearing 6203 2
81 Rotor 1
82 Stator 1
83 Cord sleeve 1
84 Hex nut 4
85 Wheel box 1
86 Philips screw 1
87 Philips screw 6
88 Disc cover 1
89 Hex screw M6 x 16 1
90 Tooth washer M6 x 16 1
91 Disc 1
92 Rubber foot 5
93 Dust hood 1
94 Wave washer φ40 1
95 Mitre gauge knob 1
96 Mitre gauge pointer 1
97 Wire connection box
cover
1
98 Mitre gauge 1
99 Protect plate 1
100 Mitre gauge rod 1
101 Disc hook 1
102 Disc paper 1
103 Wrench clip 1
104 Mitre gauge clip 1
105 Philips screw 4
106 Hex nut M4 1
107 Philips screw M4 x 12 1
108 Base plate 1
109 Motor support 1
110 Philips screw+spring
washer+flat washer
M5 x 8 1
111 Hex wrench M6 x 90 x 32 1
112 Dust plate 1
113 Philips screw+spring
washer+flat washer
M5 x 10 2
114 Philips screw M5 x 16 5
