1.6.4 Helmet/headset Connectors
Connector on MP20:
Fisher DBEU1031A010-130
Compatible cable mount :
Fisher SE1031A010-130
1.6.5 Radio characteristics
UHF Tx frequency:
409 MHz (other frequencies as customer configurations)
UHF Rx frequency:
419 MHz (other frequencies as customer configurations)
UHF Duplex separation:
10 MHz
VHF Frequency band:
156-159 MHz (only MP20-02DB series)
Channels:
16
Channel separation:
25 KHz
Modulation:
FM
Frequency stability:
25 KHz +/- 5 ppm
Receiver sensitivity
<0.9 μV at 12 dB SINAD (single band)
Output power:
400 mW (other output power as customer configurations)
Deviation:
5 KHz
Antenna impedance
50 Ω
1.6.6 Dimensions
Physical dimensions:
112 x 65.5 x 35 mm
Weight:
395g
1.6.7 Material
Material:
Aluminium 5052 (Salt Water Resistant)
Paint:
Layer1: 2 comp. Wash primer CR, Sikkens/Akzo Nobel
Layer2: 2 comp. Auto Nova – None Sanding.
Sikkens/Akzo Nobel
Layer3: 2 comp. Cooler Polyurethane Sikkens BT,
Sikkens/Akzo Nobel
Colour
BT429DS(yellow)/BT499G3(grey)
