Axxera AXA10D User Manual

6
REM (Remote Turn On)
SPEAKERS
RCA CABLES
GROUND
FUSE
12V BATTERY
MAXIMUM
12V DC
(Power)
Fuse Rating
Whenreplacingfuses,makesurenewfuse
isthecorrecttypeandamperage.Usingan
incorrect fuse could damage the amplifier.
AXA10D25ampATOx2
AXA2030ampATOx1
AXA40D40ampATOx1
Power/Ground Wire Size
Foroptimumperformance,useonlythewire
sizelistedbeloworlarger.Makesuretouse
thesamesizepowerandgroundwire.
AXA10D4awg
AXA208awg
AXA40D4awg
Main Power Connections
Connect+12V,GNDandREMwiresaccordingly.AsuitablefuseMUSTbeinstalledon
the+12Vleadwithin18"ofthebatteryforprotectionofthevehicle’selectricalsystem.
Typical Wire Routing
INSTALLATION
