Axxess AX-FD1-SWC User Manual

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
IMPORTANT
If you are having difficulties with the installation of this product,
please call our Tech Support line at 1-800-253-TECH. Before doing
so, look over the instructions a second time, and make sure the
installation was performed exactly as the instructions are stated.
Please have the vehicle apart and ready to perform troubleshooting
steps before calling.
AxxessInterfaces.com © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION REV. 7/19/17 INSTAX-FD1-SWC
INSTALLATION INSTRUCTIONS
AX-FD1-SWC
Resetting the AX-FD1-SWC
1. With the radio on, turn the potentiometer:
Note: Before proceeding, remember the position the potentiometer is at.
Turn left the LED will come on hold until the LED goes out
Turn right the LED will come on hold until the LED goes out
Turn back left the LED will come on hold until the LED goes out
Turn right the LED will come on hold until the LED goes out
Turn back left the LED will begin to flash rapidly
Turn back to the initial position
The rapid flash means the interface is starting its re-programming process.
2. The L.E.D. inside the interface will turn off for a couple seconds, then flash fast, then flash slowly (up to (18) times, indicating
which radio is connected to the interface), and then turn off. Pay close attention as to how many slow flashes there are. This
will help in troubleshooting, if need be. Refer to the L.E.D. feedback section for more information .
3. Within a few seconds the L.E.D. will turn on, and the radio will turn off.
4. Within a minute the L.E.D. will turn off, and the radio will come back on, indicating the resetting and initialization
process was successful.
Dual assignment legend
1. Not allowed
2. Not allowed
3. Seek-Up/Next
4. Seek-Down/
Prev
5. Mode/Source
6. ATT/Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT
13. On-Hook
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
* Not applicable in this application
STEERING WHEEL CONTROL SETTINGS (CONT)
