SPARE PARTS LIST
NO. DESCRIPTION NO. DESCRIPTION
1 FRONT COVER 35 FOUR-WAY VALVE CONNECT TUBE (C)
2 AIR OUTLET FRAME 36 CONDENSER ENTRANCE TUBE
3 LEVER OF HORIZONTAL AIR GUIDER 37 THREE-WAY FILTER
4 AIR GUIDER 38 CRAFWORK TUBE
5 REMOTE CONTROL RECEIVER WINDOW 39 CONDENSER OUTLET TUBE
6 LEFT-PLATE 40 FOUR-WAY VALVE
7 CONDENSER 41 DISCHARGE TUBE
8 TOP COVER 42 HYDRO-EXTRACTING MOTOR COVER
9 DISPLAY BOARD 43 HYDRO-EXTRACTING FAN
10 AIR GUIDER 44 HYDRO-EXTRACTING MOTOR
11 REMOTE CONTROL RECEIVER BOAED 45 CHASSIS
12 CONTROL PANEL 46 WHEEL
13 SENSE TEMPERATURE BRACKET 47 FLOAT FIXED FRAME
14 EVAPORATOR 48 FLOAT FIXED FRAME
15 INNER AIR DUCT (BACK) 49 MICRO SWITCH
16 INNER CENTRIFUGAL FAN 50 BACK BRACKET
17 INNER AIR DUCT (FRONT) 51 COVER OF COMPRESSOR
18 INNER FAN MOTOR 52 OVER LOADING PROTECTOR
19 POWER SUPPLY CORD 53 COMPRESSOR
20 COVER OF ELECTRICA CONTROL BOX 54 M6 NUT
21 CORD CLAMP 55 Ø6 WASHER
22 MAIN PCB 56 ANTI-VIBRATE CUSHION
23 ELECTRIC CONTROL BOX 57 FLAP JOINT POLE
24 COMPRESSOR CAPACITOR 58 RIGHT-PLATE
25 INNER MOTER CAPACITOR 59 CONNECTION TUBE
26 OUTER MOTOR CAPACITOR 60 WATER TRAY OF EVAPORATOR
27 OUTER DUCT (LEFT) 61 BACK COVER
28 OUTER CENTRIFUGAL FAN 62 BACK COVER DEFENSE NET
29 OUTER DUCT(RIGHT) 63 WINDING PLATE
30 OUTER MOTOR 64 STOPPLE DRAIN
31 EVAPORATOR OUTLET TUBE 65 CONNECTOR OF AIR EXHAUST
32 CAPILLAR CONNECT TUBE 66 AIR EXHAUST DUCT
33 FOUR-WAY VALVE CONNECT TUBE (E) 67 FLAT CONNECTOR
34 SUCTION TUBE 68 WINDOW SLIDER SECTION
