7 Master Dimmer Pixel 3 000-255 (0-100%)
8 Shutter / Strobe Pixel 3 See Pixel 1
9 Colour Macro Preset Pixel 3 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
10 Master Dimmer Pixel 4 000-255 (0-100%)
11 Shutter / Strobe Pixel 4 See Pixel 1
12 Colour Macro Preset Pixel 4 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
13 Master Dimmer Pixel 5 000-255 (0-100%)
14 Shutter / Strobe Pixel 5 See Pixel 1
15 Colour Macro Preset Pixel 5 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
16 Master Dimmer Pixel 6 000-255 (0-100%)
17 Shutter / Strobe Pixel 6 See Pixel 1
18 Colour Macro Preset Pixel 6 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
19 Master Dimmer Pixel 7 000-255 (0-100%)
20 Shutter / Strobe Pixel 7 See Pixel 1
21 Colour Macro Preset Pixel 7 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
30CH mode:
CH Function Value
1 Master Dimmer 000-255 (0-100%)
2 Shutter / Strobe 000-005 LED ON
006-015 LED OFF
016-131 LED Strobe slow-fast
132-139 LED ON
140-181 Fast on, slow off, slow-fast
182-189 LED ON
190-231 Slow on, fast off, slow-fast
232-239 LED ON
240-247 Random strobe
248-255 LED ON
3 Dimmer Red Pixel 1 000-255 (0-100%)
4 Dimmer Green Pixel 1 000-255 (0-100%)
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
