3 Dimmer Red 000-255 (0-100%)
4 Dimmer Green 000-255 (0-100%)
5 Dimmer Blue 000-255 (0-100%)
6 Dimmer White 000-255 (0-100%)
7 Colour MacroPpreset 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
8 Effect Mode 000-009 No function
010-029 Effect 1
030-049 Effect 2
050-069 Effect 3
070-089 Effect 4
090-109 Effect 5
110-129 Effect 6
130-149 Effect 7
150-169 Effect 8
170-189 Effect 9
190-209 Effect 10
210-229 Effect 11
230-249 Effect 12
250-255 Effect random
9 Effect Speed 000-249: Effect speed slow-fast
250-255: Sound-controlled mode
21CH mode:
CH Function Value
1 Master Dimmer Pixel 1 000-255 (0-100%)
2 Shutter / Strobe Pixel 1 000-005 LED ON
006-015 LED OFF
016-131 LED Strobe slow-fast
132-139 LED ON
140-181 Fast on, slow off, slow-fast
182-189 LED ON
190-231 Slow on, fast off, slow-fast
232-239 LED ON
240-247 Random strobe
248-255 LED ON
3 Colour Macro Preset Pixel 1 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
4 Master Dimmer Pixel 2 000-255 (0-100%)
5 Shutter / Strobe Pixel 2 See Pixel 1
6 Colour Macro Preset Pixel 2 000-005 No function
006-125 Fixed colour selection
126-189 Colour jump, slow-fast
190-255 Colour fade, slow-fast
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
