Ayra LED Tri-Bar 12 User Manual

3CH1 mode (RGB mode):
CH1 000-255 Dimmer red 0-100%
CH2 000-255 Dimmer green 0-100%
CH3 000-255 Dimmer green 0-100%
3CH2 mode (Show mode):
CH1 000-100 Standard shows
100-255 Special shows
Standard show selection + Special show
selection
CH2 000-255 Speed selection, applies to both show modes Speed selection slow-fast
CH3 Colour select (only applies when channel 1 value is
larger than 100)
Colour select 1-7
4CH mode:
CH1 000-007 no function
008-247 Show selection 1-16
248-255 Sound controlled mode
Show mode selection
CH2 000-255 Master dimmer 0-100%
CH3 000-007 no function
008-247 strobe slow-fast
248-255 sound controlled strobe
Strobe mode
CH4 000-255 Speed adjustment slow to fast (overruled
when sound mode is active)
6CH mode:
CH1 000-100 Standard shows
100-255 Special shows
Standard show selection + Special show
selection
CH2 000-255 Speed adjustment slow to fast
CH3 000-255 Dimmer red 0-100% (not used during
Standard Show mode)
CH4 000-255 Dimmer green 0-100% (not used during
Standard Show mode)
CH5 000-255 Dimmer blue 0-100% (not used during
Standard Show mode)
CH6 000-255 Strobe mode, slow-fast
7CH mode:
CH1 000-255 Dimmer red 0-100%
CH2 000-255 Dimmer green 0-100%
CH3 000-255 Dimmer blue 0-100%
CH4 000-255 Master dimmer 0-100%
CH5 000-007 no function
008-247 strobe slow-fast
248-255 sound controlled strobe
Strobe mode
CH6 000-007 no function
008-247 Show selection 1-16
248-255 Sound-controlled mode
Show mode selection
CH7 000-255 Speed control slow-fast (only when show
mode 1-16 is active)
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-02-2015 RV Revision date + author initials: 02-02-2015 RV
