Ayra LED Tri-Bar 12 User Manual

Technical specifications
- powerful LED pixel bar with 12x 3W RGB Tri-LED light source
- compact fixture with robust aluminium housing
- energy-efficient design, power consumption of 50 W max.
- honeycomb lens for optimal brightness and colour mixing, 5,800 lumens @ 1 m, 3,800 lumens @ 2
m!
- over 1 million colour combinations, with RGB LEDs
- DMX, automatic, master/slave and sound-controlled operating modes
- DMX mode with 1CH / 3CH1 / 3CH2 / 4CH / 6CH / 7CH / 13CH / 36CH settings
- automatic mode with Show 1, Show 2 and fixed colour settings:
- show 1: automatic mode with colourful programs, speed to be set by user
- show 2: automatic mode with exciting programs, basic colour and speed to be set by user
- fixed colours: choose from 7 basic colours
- master/slave mode with Slave 1 and Slave 2 settings:
- slave 1: normal slave mode
- slave 2: special slave mode when in sound-controlled mode, with random mirrored effects
- sound-controlled mode: To be combined with the above modes, performance in sync with the beat
of the music
- colour balance system, increase or decrease the max. intensity of basic colours for optimal colour
calibration
- high refresh rate: 2,000/4,500 Hz
- Internal test mode to check all pixels
- CPU test
- fixture working hour readout option
- firmware readout
- 4-button LED menu display with flip option
- LED display shut-down option – display can be shut off when not in use
- included brackets to use the bar standing or suspended
Connectors:
- DMX: 3p XLR male and female
- power: IEC C14 power input and IEC C13 Power Link output
Electronics:
- voltage: AC100-240 V 50/60 Hz
- active power: 50 W max.
- current: 0.4 A
- power factor: 0.555
- fuse: T3AL 250 V (not for power output)
Physical:
- fixture dimensions: 1,008 x 71 x 60 mm
- bracket height: 135 mm
- weight: 5 kg
Included accessories:
- power cable IEC C13 to Schuko (3x 1mm² )
- power cable IEC C13 to UK plug (3x 1mm² )
- hardware kit with 2 brackets and tightening knobs
Technical information:
- maximum ambient temperature (Ta): 40 degrees Celsius
- exterior surface temperature of the device in steady condition during use: 26 degrees Celsius
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 02-02-2015 RV Revision date + author initials: 02-02-2015 RV
