Ayra TDC Flower Power User Manual

Signal loss or interference in the
DMX circuit
Close the DMX circuit with a
terminator or connect a booster
after maximum 32 fixtures.
The device is not reacting properly
to DMX commands
Incorrect DMX channel mode Check that the correct DMX
channel mode is set
The operation mode can not be
changed
The device is in Slave mode If the device is in Slave mode, it
will wait for a master signal unless
there is a DMX signal present. Set
the device to Master to activate the
sound-controlled or automated
operation modes.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Ayra TDC Flower Power Specifications

Lighting

LED light source	25W RGBW
Beam angle	120 Degrees
Red projection	125-145 Lux at 1m
Green projection	230-260 Lux at 1m
Blue projection	55-65 Lux at 1m
White projection	330-360 Lux at 1m

Power

Power supply	100-240V AC, 50/60 Hz
Maximum power consumption	30 Watt
Power factor	0.6

Operating Environment

Maximum functioning temperature	0°C to 40°C
Maximum housing temperature when in normal use	55°C

Weight and Dimensions

Dimensions	210 x 90 x 130 mm
Weight	1.6 kg
