Ayra TDC Flower Power User Manual

Technical Specifications
Features:
- LED Flower Power light effect
- Rotating optics for special light rays
- 25W RGBW LED light source
- LED Display with Menu buttons
- Diverse operation modes
- Automatic modes
- Sound / Music-Controlled mode with adjustable sensitivity
- Master / Slave function
- DMX controlled via 8 channels
- Operation modes: Automatic, Sound / Music-Controlled, Master / Slave, DMX
- DMX connection via 3-pin XLR input and output
Technical Details:
- Power supply: 100-240V AC, 50/60 Hz
- Maximum power consumption: 30 Watt
- Power factor: 0.6
- Fuse: F3AL250V
- Light source: 1x 25W RGBW multichip LED
- Maximum functioning temperature: 0°C to 40°C
- Maximum housing temperature when in normal use: 55°C
- Dimensions: 210 x 90 x 130 mm
- Weight: 1.6kg
Projection Data:
- Beam angle: 120 Degrees
- Red projection: 125-145 Lux at 1m
- Green projection : 230-260 Lux at 1m
- Blue projection: 55-65 Lux at 1m
- White: 330-360 Lux at 1m
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Ayra TDC Flower Power Specifications

Lighting

LED light source	25W RGBW
Beam angle	120 Degrees
Red projection	125-145 Lux at 1m
Green projection	230-260 Lux at 1m
Blue projection	55-65 Lux at 1m
White projection	330-360 Lux at 1m

Power

Power supply	100-240V AC, 50/60 Hz
Maximum power consumption	30 Watt
Power factor	0.6

Operating Environment

Maximum functioning temperature	0°C to 40°C
Maximum housing temperature when in normal use	55°C

Weight and Dimensions

Dimensions	210 x 90 x 130 mm
Weight	1.6 kg
