Page #28 background imageLoading...
Page #28 background image
Numbers and
Specifications
Input Impedance 2 MΩ balanced (1 MΩ per phase)
1 MΩ single-ended
XLR Input Polarity Pin 1 = Ground
Pin 2 = Non-inverting (Positive)
Pin 3 = Inverting (Negative)
Gain Variable
Frequency Response DC – 250 kHz
Output Impedance 300 Ω balanced (150 Ω per phase)
150 Ω single-ended
Power Consumption 35 watts;
65 watts maximum (when operating the volume control)
Dimensions 17-¼" W x 11-¾" D x 3-¾" H
(44 cm x 30 cm x 9.5 cm)
Weight 42 pounds
(19 kg)
28
