USER MANUAL _ 19
SOFTWARE FEATURES
• Full menus for setting DMX address and advanced functions
• Compatible with the DMX/RDM (Remote Device Management) protocol
• Pre-programmed macro modes
• Information menu including: timer, temperature, software version, etc.
CONTROL
• USITT DMX512 – ArtNet - sACN
• DMX RDM-compatible
• Clicking Jog Wheel
• DMX512 input/output
• Choice of 3 DMX modes (from 40 to 64 channels)
• Wireless System: LumenRadio wireless CRMX RDM receiver
POWER SUPPLY
• Electronic power distribution with Power Factor Correction (PFC) from
110-240 VAC, 50/60 Hz
• 1150 Watt maximum power
• Power supply via powerCON TRUE1 connector
• Supplied power cable without plug
• Optional battery for addressing without external power source: Li-ion
ICR14500 ≥ 350mAh – 3,7V
COOLING
• Advanced forced-air cooling system
• Self-adjusting fan for reduced noise level (in AUTO mode)
• User-selectable air-cooling modes
CONSTRUCTION
• Covers: molded PC-ABS thermoplastic, class V0 (fire retardant)
• Chassis: steel plates and aluminum
• 2 handles for transport
• Protection rating: IP20 (indoor use only)
• Finish: Carbon black
INSTALLATION
• 2 OMEGA brackets with quarter-turn locks included
• Safety cable attachment not included
OPERATING PARAMETERS
• Operating positions: on floor or attached to a support
• Maximum authorized ambient temperature (Ta Max): 45°C
• Minimum authorized ambient temperature (Ta Min): -5°C
• Minimum projection distance: 5 m
DIMENSIONS
• Product: 494 mm x 737 mm x 280 mm (L x H x D)
• Protective foam: 655 mm x 590 mm x 555 mm (L x H x D)
WEIGHT
• Product: 39,8 kg
PRODUCT CODE
• 011640: KHAMSIN-S WASH LUMINAIRE
• 011650: KHAMSIN-TC WASH LUMINAIRE
FOAM FOR FLIGHT CASE
KHAMSIN is delivered in a carton packed with a dense, protective foam
surrounding the fixture. This reusable protective shell is intended for a
flight case that can be custom built for the luminaire.
AYRTON does not offer custom flight cases for the KHAMSIN. This
accessory is to be provided by the user.
The main dimensions of the protective shell appear in the following
diagram:
Section : B-B
Section : A-A
WARRANTY
The AYRTON KHAMSIN fixture is guaranteed against manufacturing
defects for the duration of two (2) years from the date of purchase.
This warranty does not cover the unit for evidence of physical shock or
damage caused by abuse or any use not in accordance with the operating
conditions set forth in the present user manual.
In addition, cosmetic defects caused by the normal wear and tear of the
unit are not covered under the warranty.
Any modification to the fixture will void the warranty. AYRTON cannot under
any circumstances be held liable for quality and conformity regarding the
installation of this product, which is the responsibility of the installer.
Broken glass lenses on the KHAMSIN, and any damage that could arise
thereof, are excluded from the warranty. Any possible cosmetic defects,
provided you report them to your AYRTON dealer upon unpacking the
device and before use, may be covered by the warranty.
Note:
The manufacturer is not responsible for any errors or omissions that may
occur in this document. All information contained in this manual is subject
to change without notice.
