USER MANUAL _ 15
amount: 250 scenes)
Press ENTER to confirm.
Press MODE/ESC to return to the main menu.
Example:
”Program 2” includes scenes: 10, 11, 12, 13.
”Program 4” includes scenes: 8, 9, 10.
”Program 6” includes scenes: 12, 13, 14, 15.
”Auto Program Part 1” is “Program 2.”
”Auto Program Part 2” is “Program 3.”
”Auto Program Part 3” is “Program 6.”
The 3 groups of SLAVE fixtures run the “Auto Program” function in the
following sequence:
Part 1:
Scene 10 Scene 11 Scene 12 Scene 13
Part 2:
Scene 8S cene 9S cene 10 Scene 8
Part 3:
Scene 12 Scene 13 Scene 14 Scene 15
DMX CHART
THE following chart shows the functions and corresponding values for
each DMX channel according to mode whether Standard (St), Basic (Ba)
or Extended (Ex):
DMX channel´s functions and their values (64DMX channels):
Mode/Channel Value Function
St Ba Ex
1 1 1
PAN Movement 8bit
0-255 Pan Movement
2 2
Pan Fine 16bit
0-255 Fine control of Pan movement
3 2 3
TILT Movement 8bit
0-255 Tilt Movement
4 4
Tilt Fine 16bit
0-255 Fine control of Tilt movement
5 3 5
Speed Pan/Tilt movement:
0-225 max to min speed
226-235 blackout by movement
236-245 blackout by all wheel changing
246-255 no function
6 4 6
Shutter, strobe
0-31 Shutter closed
32-63 No function (shutter open)
64-95 Strobe effect slow to fast
96-127 No function (shutter open)
128-159 Pulse-effect in sequences
160-191 No function (shutter open)
192-223 Random strobe effect slow to fast
224-255 No function (shutter open)
7 5 7
Dimmer intensity:
0-255 Intensity 0 to 100%
8
Fine Dimmer intensity:
0-255 Dimmer intensity fine
8 6 9
Chase Patterns
0-9 Open
10-19 Chase 1
20-29 Chase 2
30-39 Chase 3
40-49 Chase 4
50-59 Chase 5
60-69 Chase 6
70-79 Chase 7
80-89 Chase 8
90-99 Chase 9
100-109 Chase 10
110-119 Chase 11
120-129 Chase 12
130-139 Chase 13
140-255 Reserved
9 7 10
Chase Speed
0-125 Fast to Slow Backward
126-130 Stop
131-255 Slow to Fast Forward
10 8 11
Chase Fade
0-255 Fade Chase
11 9 12
Zoom :
0-255 Zoom adjustment from small to big
