Ayrton Khamsin - Page 16

USER MANUAL _ 16
DMX channel´s functions and their values (64DMX channels):
Mode/Channel Value Function
St Ba Ex
13
Zoom Fine:
0-255 Zoom adjustment Fine
12 10 14
Focus :
0-255 Continuous adjustment from near to far
15
Focus Fine:
0-255 Continuous adjustment Fine
13 11 16
Auto Focus :
0-50 Auto Focus Off
51-100 5m
101-150 7.5m
151-200 10m
201-255 15m
14 12 17
AutoFocus Fine:
0-255 Continuous adjustment Fine
15 13 18
Color Wheel:
0-17 Open / white
18-35 Color 1 (CRI Filter)
36-53 Color 2 (Congo Blue)
54-71 Color 3 (Green)
72-89 Color 4 (Orange)
90-107 Color 5 (Light Blue)
108-127 Color 6 (Red)
128-189 Forward rainbow effect from fast to slow
190-193 No rotation
194-255 Backward rainbow effect from slow to fast
19
Color Wheel Fine :
0-255 Color Wheel colour change to any position Fine
16 14 20
CTB / CRI
0-63 Open
64-127 CTB
128-255 CRI
17 15 21
Cyan Color :
0-255 Cyan (0-white, 255-100% Cyan)
22
Cyan Color Fine :
0-255 Cyan Fine
18 16 23
Magenta Color :
0-255 Magenta (0-white, 255-100% magenta)
24
Magenta Color Fine :
0-255 Magenta Fine
19 17 25
Yellow Color :
0-255 Yellow (0-white, 255-100% Yellow)
26
Yellow Color Fine :
0-255 Yellow Fine
20 18 27
CTO Color :
0-255 CTO (0-white, 255-100% CTO)
28
CTO Color Fine :
0-255 CTO Fine
DMX channel´s functions and their values (64DMX channels):
Mode/Channel Value Function
St Ba Ex
21 19 29
Rotating gobos, cont. rotation 1:
0-9 Open
10-23 Rot. gobo 1
24-37 Rot. gobo 2
38-51 Rot. gobo 3
52-65 Rot. gobo 4
66-79 Rot. gobo 5
80-93 Rot. gobo 6
94-109 Gobo 1 shake slow to fast
110-125 Gobo 2 shake slow to fast
126-141 Gobo 3 shake slow to fast
142-157 Gobo 4 shake slow to fast
158-173 Gobo 5 shake slow to fast
174-189 Gobo 6 shake slow to fast
190-221 Gobo wheel rotation forwards from fast to slow
222-223 No rotation
224-255 Gobo wheel rotation f backwards from slow to fast
22 20 30
Rotating gobo index,rotating gobo rotation 1:
0-127 Gobo indexing
128-189 Forwards gobo rotation from fast to slow
190-193 No rotation
194-255 Backwards gobo rotation from slow to fast
31
Rotating gobo indexing Fine 1:
0-255 Fine indexing
23 21 32
Rotating gobos, cont. rotation 2:
0-9 Open
10-23 Rot. gobo 1
24-37 Rot. gobo 2
38-51 Rot. gobo 3
52-65 Rot. gobo 4
66-79 Rot. gobo 5
80-93 Rot. gobo 6
94-109 Gobo 1 shake slow to fast
110-125 Gobo 2 shake slow to fast
126-141 Gobo 3 shake slow to fast
142-157 Gobo 4 shake slow to fast
158-173 Gobo 5 shake slow to fast
174-189 Gobo 6 shake slow to fast
190-221 Gobo wheel rotation forwards from fast to slow
222-223 No rotation
224-255 Gobo wheel rotation f backwards from slow to fast
24 22 33
Rotating gobo index,rotating gobo rotation 2:
0-127 Gobo indexing
128-189 Forwards gobo rotation from fast to slow
190-193 No rotation
194-255 Backwards gobo rotation from slow to fast
24 22 33
Iris:
0-191 Max. diameter to Min.diameter
192-223 Pulse closing fast to slow
224-255 Pulse opening slow to fast
34
Rotating gobo indexing Fine 2:
0-255 Fine indexing
25 23 35
Animation wheel:
0-7 open
8-127 Forwards rotation from fast to slow
128-135 No rotation
136-255 Backwards rotation from slow to fast
