USER MANUAL _ 17
DMX channel´s functions and their values (64DMX channels):
Mode/Channel Value Function
St Ba Ex
26 24 36
Iris:
0-191 Max. diameter to Min.diameter
192-223 Pulse closing fast to slow
224-255 Pulse opening slow to fast
37
Iris Fine:
0-255 Iris Fine
27 25 38
Prism 1:
0-127 Open
128-255 5-Facet Prism
28 26 39
Rotating prism index, rotating prism rotation 1
0-127 Prism indexing
128-189 Forwards prism rotation from fast to slow
190-193 No rotation
194-255 Backwards prism rotation from slow to fast
40
Rotating prism indexing Fine 1:
0-255 Fine indexing
29 27 41
Prism 2:
0-127 Open
30 28 42
Rotating prism index, rotating prism rotation 2
0-127 Prism indexing
128-189 Forwards prism rotation from fast to slow
190-193 No rotation
194-255 Backwards prism rotation from slow to fast
43
Rotating prism indexing Fine 2:
0-255 Fine indexing
31 29 44
Frost 1:
0-255 0-100%
32 30 45
Frost 2:
0-255 0-100%
33 31 46
Blade 1 A:
0-255 Open to Close
47
Blade 1 A Fine:
0-255 Open to Close Fine
34 32 48
Blade 1 B:
0-255 Open to Close
49
Blade 1 B Fine:
0-255 Open to Close Fine
35 33 50
Blade 2 A:
0-255 Open to Close
51
Blade 2 A Fine:
0-255 Open to Close Fine
36 34 52
Blade 2 B:
0-255 Open to Close
53
Blade 2 B Fine:
0-255 Open to Close Fine
37 35 54
Blade 3 A:
0-255 Open to Close
55
Blade 3 A Fine:
0-255 Open to Close Fine
38 36 56
Blade 3 B:
0-255 Open to Close
57
Blade 3 B Fine:
0-255 Open to Close Fine
39 37 58
Blade 4 A:
0-255 Open to Close
DMX channel´s functions and their values (64DMX channels):
Mode/Channel Value Function
St Ba Ex
59
Blade 4 A Fine:
0-255 Open to Close Fine
40 38 60
Blade 4 B :
0-255 Right Blade Rotation
61
Blade 4 B Fine:
0-255 Right Blade Rotation Fine
41 39 62
All Blade Rotation:
0-255 All Blade Rotation
63
All Blade Rotation Fine:
0-255 All Blade Rotation Fine
42 40 64
Reset, internal programs:
0-4 Not used
5-9 Display Off
10-14 Display On
15-19 Display Invert Off
20-24 Display Invert On
25-29 Auto fan control mode
30-34 Stage fan control mode
35-39 Studio fan control mode
40-44 Silence fan control mode
45-49 Square Law
50-54 Linear
55-59 1.2K
60-64 2.4K
65-69 16K
70-74 Gobo Correction OFF
75-79 Gobo Correction ON
80-84 All motor reset
85-87 Pan & Tilt motor reset
88-90 Color motor reset
91-93 Gobo motor reset
94-96 Not used
97-99 Other motor reset
100-119 Internal program 1 (scene1~8 of EEPROM)
120-139 Internal program 2 (scene9~16 of EEPROM)
140-159 Internal program 3 (scene17~24 of EEPROM)
160-179 Internal program 4 (scene25~32 of EEPROM)
180-199 Internal program 5 (scene33~40 of EEPROM)
200-219 Internal program 6 (scene41~48 of EEPROM)
220-239 Internal program 7 (scene49~56 of EEPROM)
240-255 Internal program 8 (scene49~56 of EEPROM)
