Specifications
» Bi-directional
» Automatic direction control
» Maximum data rates: 110 Mbps (push pull)
1.2 Mbps (open drain)
» Low voltage 1.4 to 3.6 V
» High voltage 1.65 to 5.5 V
» Dimensions: 26 x 16 mm
Logic Level Converter TXS0108E is an 8-bit non-inverting level converter
which uses two separate configurable power-supply rails. This device is
created for open-drain applications, but it also can translate push-pull
CMOS (complementary metal-oxide-semiconductor) logic outputs.
The A-port accepts I/O voltages varying from 1.4 V to 3.6 V. The B-port
accepts I/O voltages from 1.65 V to 5.5 V.
Electrostatic Discharge Caution: This device has limited built-in ESD
protection. To prevent electrostatic damage to the MOS (Metal Oxide
Semiconductor) gates, the leads should be shorted together or the device
placed in conductive foam during storage or handling.
For further information on open drain circuitry we provide the link to
Wikipedia here.
