Appendix A: Specifications
A-19
[For double-acting actuator without KZ03 regulator] unit: mm
[For double-acting actuator with KZ03 regulator] unit: mm
70 138
145 180
82
41.5
(220)
150
97 138
179 180
82
(270)
150
