A-20
Dimensions (Model AVP200/201/202)
[Single-Acting, without Pressure Regulator]
unit: mm
187
80
*2
Supply air connection
2B pipe
Auto/manual switch
Mounting bracket
U bolts and nuts
*3
41 41
±4° to ±20°
137 92 to 122
*4
210
Dedicated cable
Fasten properly in accordance with electrical
equipment technical standards.
21
70
98
42 71
*2
Output air connection
*1
Electrical wiring connection
*1
Electrical wiring connection
*2
Supply air connection
72
46
83
72
Explosion-proof
model
237
Ground terminal screw
Ground terminal screw
Terminal box terminal connection diagram
Terminal screw size: M4
Terminal connection diagram
Terminal screw size: M4
AVP200/202 AVP201
For rotary valve
Main Unit Structure Electrical conduit Air pipe
Installation Screws
AVP Main Unit Position Detector
TIIS flameproof model, regular model G1/2 Rc1/4 M8 M6
Regular model 1/2NPT 1/4NPT 5/16-18UNC 1/4-20UNC
Notes *1 *2 *3 *4
To Next Page
