Auxiliary parts
< Immersion well >
Figure 2. Dimensions of Model 112624AA-J (mm)
< Pressure tting >
Figure 3. Dimensions of Model 83165370-001 (mm)
< Temperature sensor holder >
Figure 4. Dimensions of Model DY3002A1011 (mm)
14
φ14.3
140
R1/2 screw
Seal ring
16
50
30
23
8
1/2NPT
Packing
Capillary
tube
2543
Washers (x4)
Nut
(2)
22.4
356
Accessories: tapping screws (x2)
Nominal diameter 4.5, L=16
2
17.5
3535
41.3
82.6
14.3
φ4.6 Mounting hole
17.5
φ6.4 Mounting hole
(3.5)
t0.5
10
φ5
19
(47.5)
82.6
41.3
(16.5)(31)
