Azbil TY6800Z Series User Manual

Name: Azbil TY6800Z Series
Brand: Azbil
Rating: 4 (1 reviews)

20 pages

To Next Page

To Previous Page

AB-6600

Figure 7. Mounting wall/panel dimensions (mm)

Figure 8. Installation procedure

106.4

4.5 Hole

(Wall or panel)

Mounting nuts (x3)

Accessories: M4

Mounting screws (x3, accessories)

M4, L=12

Wall plate

t1.6

～

3.2

Main unit
