15.2 Rack for PCBs
The assembly and connection of the boards is made to another board type «RACK» that is fixed to
the chassis of the power supply and that allows the connection of the boards in any of the slots as
the lines are in parallel (similar to the expansion slots on a computer).
U
On inserting any board in the RACK, take special care to check the correct
position of the pins, avoiding the bending of them following malfunctions of
the system
Rack board with two connections
