1ª 10155 ES 9 - 2009
43
From factory all the channels are prepared for selling Standard type packets
of cigarettes
The following table shows the possible combinations of lengths and heights of the product.
1-A 1-B 2-A 2-B 3-A 3-B 4-A 4-B 5-A 5-B
THICKNESS 14-17 14-17 17-22 17-22 20-26 20-26 24-31 24-31 28-36 28-36
LENGTH(1) 79-89 66-76 79-89 66-76 79-89 66-76 79-89 66-76 79-89 66-76
LENGTH(2) 94-104 81-91 94-104 81-91 94-104 81-91 94-104 81-91 94-104 81-91
3.1.5. Changing prices
From the programming of the machine, you can change the prices assigned to each of the
selections.
For more information see the Programming Manual
3.1.6 Changing the Product labels
To access the Product labels, follow the instructions below:
With a Phillips screwdriver, remove the transport
screws that are indicated with the yellow arrows in
the figure lateral and tilt down the grid of channels
in the door.
