Planning Your Network
Before moving ahead to setup your network, it is a good idea to draw out a network diagram to
help identify your network devices and plan out how to connect these devices. The illustration
below is an example of a network diagram.
Each port in the router can be used for different connections. For example:
 Ethernet 1 – connect to a desktop
 Ethernet 2 – connect to a set top box
 Ethernet 3 – connect to a Smart TV
 Ethernet 4 – connect to a Game console
 Wireless – connect a wireless laptop to the built in wireless access point
To create a network diagram:
 For wireless devices, identify the wireless devices you want to include in the
network.
 For wired devices, identify which router port you want to use for each device.
