User Manual
Page 6 of 43
DEVICE DESIGN
Lens with IR reflection coating
Press and hold for over 1 second to reset factory default
Press 1 to 3 seconds to enter into “Pairing Procedure” (creating
an encrypted PLC network).
While it’s under “Pairing Procedure”, press and hold for 2 to 3
seconds to stop the procedure.
Press and hold for 10 seconds to remove current encrypted
network and generate a new one.
OFF:
No PLC device is detected nor connected.
ON: PLC device is detected.
Blinking:
1. Fast: PLC UDP data transfer rate is higher than 60Mbps.
2. Normal: PLC UDP data transfer rate is between 10Mbps to
60Mbps.
3. Slow: PLC UDP data transfer rate is slower than 10Mbps.
ON: Power on and ready
Blinking:
1. During “Pairing Procedure” (creating an encrypted PLC
network). The device is creating or being joined into the
same encrypted network and will last 2 minutes until it is been
succeeded or canceled.
OFF: Power off.
