B-52 ACTPRO Active Systems - Instruction Manual
ACTPRO
18
CONNECTIONS
EXAMPLE #5
This example shows the set-up of a pair of ACTPRO12M loudspeakers to be used as stage monitors. The
audiosignalisprovidedbyamixer,aProdigyFXinthisexample.Somemixershaveamonomonitor
output but in this case you can daisy-chain a few ACTPRO12M speakers by connecting the INPUT of one
totheOUTPUTofanotherwithanXLRcable.
Note:It is recommended to turn the LOW-CUT switch ON for better clarity in guitar and voice ranges
and avoid LF build-up on the stage.
Note:You can add the ACTPRO12M as a monitor to any of the previous examples (1 through 4) or to
any other set-up.
