B3C Serenite 9260(A) - Battery Operation; Technical Data

ENGLISH
9
11
BATTERY OPERATION
The scale can be operated from the battery if desired. The battery life is
approximately 30-70 hours.
When the battery needs charging a symbol “ ” on the weight display will be on.
The battery should be charged when the symbol is on.
The scale will still operate for about 10 hours after which it will automatically switch off to pro-
tect the battery.
There is an LED “AC” to indicate the status of battery charging on the right of display.
When the scale is plugged into the mains power the internal battery will be charged.
If it the led is green
●
: the battery has been charged.
If it the led is red
●
: the battery is nearly discharged.
If it the led is yellow
●
: the battery is increasing the charge level.
NOTE
The battery should changed if the scale is not used for long time
12
TECHNICAL DATA
Désignations 9360.03 9260.03 9360.06 9260.06 9360.15 9260.15 9360.30 9260.30
Weighting range (Max) 3kg 6kg 15kg
30kg
Readability (d) 0,05g 0,1g 0,1g 0,2g 0,2g 0,5g
0,5g 1g
Verication “M” non
Calibration 1kg (M1) 2kg (M1) 5kg (M1)
10kg (M1)
Power supply SAW-0801000 Input 100-240VAC 50/60Hz 0.5A (max) - Output 8V=1000A (ref 618.12080)
Battery life 6V 4AH (ref 590.003) - 50h (backlight on) - 60h (backlight off) - Loading time : 12 h
Permissible ambient temperature de 0°C à + 40°C
Rate of humidity Max 80%
Carter L X P X H (mm) (L) 300 x (P) 320 x (H) 115
Plateau (mm) (L) 300 x (P) 220
Protecting cover YES
Net weight (kg) 3,8kg
