CONTROL PANEL LAYOUT

FRONT PANEL LAYOUT

1. Reset Button

2. Power Button

3. Volume/ Sel Button

4. Mute Button

5. Preset EQ/ Button

6. Time- Display/ Adjustment

7. Mode Switch

8. Remote Control Sensor

9. Band/ Button 20.USB socket

10. Tuning/ Selecting Tracks

11. LOC/ DX Selector

12. MO/ ST Selector

13. Preset Stations/ AMS

14. Number Button

15. Eject Button

16. DISC Slot

17. LCD Display

18. Release Button

19. Flashing LED

20. USB socket

21. SD/MMC Slot

22. Loudness Button

23. AUX IN
