GENERAL
Power Supply Requirements:DC14.4V , Negative Ground
Current Consumption (max): 15 Ampere
Load Impedance: 4ohms
Maximum Output Power: 50W x 4CH
Chassis Dimensions: 178 x 163 x 50 mm (W x D x H)
DVD DECK SECTION
Discs Played: DVD, MPEG4, DIVX, VCD 1.0/2.0/3.0,
MP3, WMA, CD, CD-R, CD-RW, PICTURE-CD
Video System: AUTO/PAL/NTSC
Mounting Angle: 0º~30º
VIDEO SECTION
Video System: 4:3 Letter Box 4:3 PAN SCAN 16:9
Video Output Level: 1.0VP-P 75ohms
AUDIO SECTION
Maximum Output Level: 2VRMS (+3 dB)
Frequency Response: 20~20Khz
Signal-to-noise ratio: 65dB
Separation: 60dB
FM TUNER SECTION
Tuning Range: 87.5-107.9Mhz.
IF: 10.7Mhz
Usable Sensitity: (-30dB) 15dB
Signal-to-no ratio: 60dB
Stereo Separation: 30dB (1Khz)
Frequency Response: 30~15000 Hz
AM TUNER SECTION
Tuning Range: 530-1710Khz
IF: 450Khz
Usable Sensitivity (-20dB): 28dB
NOTE: Desing and specifications are subject to change without notice for improvements.
SPECIFICATION
