B52 DV-8772 - CONTROL PANEL LAYOUT; FRONT PANEL LAYOUT

CONTROL PANEL LAYOUT
FRONT PANEL LAYOUT
5
1 RESET BUTTON
2 POWER SWITCH BUTTON
3 VOLUME/SEL (LOGO TELEFONO) BUTTON
4 PRESET EQ/ (LOGO TELEFONO) BUTTON
5 REMOTE CONTROL SENSOR
6 BAND BUTTON / ID3 SELECT
7 TUNING/SELCTING TRACKS/FW/RW
8 EJECT BUTTON
9 MODE SWITCH BUTTON
PRESET STATIONS/AMS
11 NUMBER BUTTON
12 DISC SLOT
13 TFT DISPLAY
14 RELEASE BUTTON
15 FLASHING LED
16 USB CONNECTER
17 SD/MMC SLOT
18 AUX IN
19 MO/ST SELECTOR
1
8
1215
10
