Step 7.4: A aching the side panels
Important! When a aching the side panels, make sure that the labelling on
the side panels is on the outside of the cargo box.
1. A ach both side panels to a connec on profi le (rear) by means of a bolt
inserted in the bo om hole (detail picture O) and a bolt with tube piece in
the middle hole (detail picture N). The holes at the top of both panels will stay
unused for now.
Important! Adhere to the specifi ed order for nuts, bolts and washers etc. in
order to secure everything in the best possible way (see detail pictures N and
O).
Parts needed:
- 2x side panels
- Sachet F (4x M6 bolts, 4x M6 cap nuts, 4x M6 spring washers,
8x M6 washers, 2x tube pieces)
Tools needed:
- Open-end spanner # 10
- Philips screwdriver
N.
O.
