Babboe Curve - Step 7.6: Attaching Front Connection Profiles

25
Step 7.6: A aching the connec on profi les (front)
1. A ach both connec on profi les (front) to the side panels by inser ng a bolt
in the bo om hole (detail picture Q) and a bolt with tube piece in the middle
hole (detail picture R). The holes at the top of both panels will stay unused for
now.
Important! Adhere to the specifi ed order for nuts, bolts and washers etc. in
order to secure everything in the best possible way (see detail pictures Q
and R).
Parts needed:
- 2x connec on profi les (shortest steel profi les in Box II)
- Sachet H (4x M6 bolts, 4x M6 cap nuts, 4x M6 spring washers,
8x M6 washers, 2x tube pieces)
Tools needed:
- Open-end spanner # 10
- Philips screwdriver
Q.
R.
