Babboe Curve - Step 8.3: Attaching Bars Inside Cargo Box

33
Step 8.3: A aching the bars inside the cargo box
1. A ach both bars using the nuts, bolts and washers from sachet K in the
unused holes of the side panels in the cargo box, as illustrated in Figure 37
and detail picture AC.
Important! Adhere to the specifi ed order for nuts, bolts and washers in order
to secure everything in the best possible way (see detail picture AC).
37.
AC.
Parts needed:
- 2x bars, (Box I)
- Sachet K (4x M6 bolts, 4x M6 cap nuts, 4x M6 spring washers,
8x M6 washers)
Tools needed:
- Open-end spanner # 10
- Philips screwdriver
!
