USE OF THE CHILD SEAT (GROUP 1)
Approved for the following age group (Group 1)
The use of the child seat safety belt is approved for children with a body
weight between 9 and 18 kg, aged 9 months to 4 years.
Height-adjustable shoulder strap ( group 1 )
Check that the shoulder straps are at the correct height for your child. The
straps must be passed through the slots. The child's shoulder strap must be
fastened to the bottom of the seat.
If the height of your car seat does not t your child's height, you must adjust
the height of the belt. Proceed as follows:
1 2
Loosen the belt and then turn the
child seat around so that you have
the back in front of you.
Slide the two shoulder straps onto
the connector.
NO - too low! NO - too high! YES - right!
