Figure 1. Series 3000 Cooling Tower

SERIES 3000 COOLING TOWER

Unit Operation and Storage

Start-Up Procedure

General

• Iftheunitismountedonvibrationisolatorsorisolationrails(byothers),refertothe

vibrationisolationmanufacturer’sguidelinesbeforeloading/unloadingweightfromthe

unit.

• Verifythefanandsystempumpmotorsaredisconnected,lockedout,andtaggedout.

BALTIDRIVE



PowerTrain

HotWater

BasinandCover

ColdWater

Basin

FanDeck

AirIntakeLouvers

FanGuard

TopWaterInlet

Casing

Make-upValve

AdjustableFloat

WaterOutlet

Connection

Suction

Strainer

BACross

Fillwith

IntegralDrift

Eliminators

DANGER: Do not perform any

service on or near the fans, motors,

and drives, or inside the unit

without ﬁrst ensuring that the

fans and pumps are disconnected,

locked out, and tagged out.
