The highly sensitive MZF Draft Gauge requires no liquid or
tedious leveling; this dry type instrument is always ready
for immediate use. The pointer’s movement over scale is
in direct proportion to the magnitude of the draft at the
test point. Ideal for residential, commercial and industrial
heating plants; to measure furnace draft pressure drop
across air filters.
This pocket size instrument is conveniently held in one hand
when being used, making it extremely suitable for heating
contractors and service technicians. The free-floating
pointer indicates sudden changes from draft to pressure
caused by “puffbacks.” Suitable for checking flue pipe,
chimney, fire box, smoke hood, smoke pipe draft, draft
regulator, oil burner firing rate, and basement ventilation.
These dependable, service-free draft gauges are small, inexpensive
and easy to use. Both the MZF Draft Gauge and the Draftrite
®
Pocket
Gauge can be utilized by both contractors and service technicians for
determining draft and pressure problems in commercial and
residential settings.
MZF Draft
Gauge
Draftrite
®
Pocket Gauge
PORTABLE MANOMETER
A valuable instrument for measuring and adjusting the inlet and manifold pressure for
gas heating equipment and appliances. The Bacharach
®
Manometer is designed for
accuracy, readability and portability. Used to measure pressure in gas lines and to adjust
pressure for all types of gas burning appliances. Also used to determine filter resistance,
fan efficiency, air velocity and static pressures.
ORDERING INFORMATION
ORDERING INFORMATION
Note: All models supplied with two sections of
draft tube and Leatherette Case 13-0003.
Note: All models supplied with 5” draft tube and
9’ of rubber tubing.
PART NO. RANGE
13-3000 +0.10 to 0 to -0.14” WC
13-3001 +0.05 to 0 to -0.25” WC
13-3002 +2.5 to 0 to -3.5 mm WC
13-3003 +1.5 to 0 to -6.5” mm WC
13-5010 Draftrite
®
Tube Set
PART NO. RANGE
13-7018 +1.0 to 0 to -5 mm WC
13-7019 +0.05 to 0 to -0.25” WC
13-7021 +0.05 to 0 to -1.0” WC
ORDERING INFORMATION
PART NO. DESCRIPTION
17-7000 0-15 INWC and 0-8.5 oz. per sq/in
17-7002 0-15 INWC and 0-38 cm WC
17-0025 Replacement fluid
