Backyard Discovery 2106536D - Page 6

Wood Components (Not to Scale)
OWNER'S MANUAL - PARTS IDENTIFICATION
RAFTER- W4L16286
1 3/8"x3 3/8"x20 7/16" (36x86x519)
E03
(2)
RAFTER- W4L16285
1 3/8"x3 3/8"x44" (36x86x1117)
E04
(2)
RAFTER - W4L17402
1 3/8"x3 3/8"x42 7/8" (36x86x1087)
E05
(2)
RAFTER- W4L16284
1 3/8"x3 3/8"x44" (36x86x1117)
E01
(2)
RAFTER- W4L16288
1 3/8"x3 3/8"x63 7/8" (36x86x1622)
E02
(4)
RAFTER - W4L16287
1 3/8"x3 3/8"x20 7/16" (36x86x519)
E06
(2)
RAFTER- W4L17401
1 3/8"x3 3/8"x42 7/8" (36x86x1087)
E07
(2)
RAFTER - W4L16302
1 3/8"x3 3/8"x21 3/4" (36x86x553)
E12
(2)
RAFTER- W4L16298
1 3/8"x3 3/8"x55 13/16" (36x86x1417)
E09
(2)
RAFTER- W4L16300
1 3/8"x3 3/8"x21 3/4" (36x86x553)
E10
(2)
BEAM- W4L16926
| 1 3/8"x5 1/4"x30 15/16" (36x134x786)
D01
(4)
RAFTER W4L16290
1 3/8"x3 3/8"x63 7/8" (36x86x1622)
E11
(2)
BEAM- W4L16927
| 1 3/8"x5 1/4"x55 3/4" (36x134x1416)
D02
(2)
