Wood Components (Not to Scale)
OWNER'S MANUAL - PARTS IDENTIFICATION
SHEATHING BOARD - W4L13662
1 3/8"x3 3/8"x87 1/4" (36x86x2217)
E4
(x8)
RAFTER - W4L13666
1"x3 3/8"x79 3/8" (24x86x2016)
H1
(x2)
END RAFTER - W2A03020
2 13/16"x5 1/4"x80 5/8" (72x134x2048)
RP1
(x2)
POST - W2A03484
6"x6"x89 1/2" (152x152x2274)
P1
(x2)
POST - W2A03021
6"x6"x33 1/4" (152x152x845)
P3
(x2)
END RAFTER - W2A03022
2 13/16"x5"x80 5/8" (72x134x2048)
RP2
(x2)
POST - W2A03485
6"x6"x89 1/2" (152x152x2274)
P2
(x2)
RIDGE CAP STIFFENER - W4L17392
1"x2 3/8"x60 7/8" (24x60x1546)
J60
(x2)
RIDGE CAP STIFFENER - W4L17393
1"x2 3/8"x82 1/2" (24x60x2096)
J61
(x2)
SHEATHING BOARD - W4L13659
1 3/8"x3 3/8"x58 1/4" (36x86x1478)
E3
(x8)
RAFTER - W4L13667
1"x3 3/8"x53 11/16" (24x86x1364)
H3
(x2)
FASCIA - W4L13668
1"x3 3/8"x59 3/4" (24x86x1518)
H4
(x2)
FASCIA - W4L13663
1"x3 3/8"x85 3/8" (24x86x2170)
H2
(x2)
