Backyard Discovery ASHLAND - Page 13

Owner's Manual
Wood Components (Not to Scale)
Parts Identification
PERGOLA POST - W2A02957
5 1/2"x5 1/2"x89 1/2" (140x140x2273)
UP4
(x1)
PERGOLA POST - W2A02952
5 1/2"x5 1/2"x89 1/2" (140x140x2273)
UP1
(x1)
PERGOLA POST - W2A02955
5 1/2"x5 1/2"x89 1/2" (140x140x2273)
UP2
(x1)
PERGOLA POST - W2A02956
5 1/2"x5 1/2"x89 1/2" (140x140x2273)
UP3
(x1)
WALL PANEL - W2A02953
2 3/8"x15 7/8"x84 1/2" (60x403x2146)
WP1
(x1)
TABLE TOP PANEL - W2A02954
1 9/16"x20 1/2"x84 7/16" (40x521x2145)
TP1
(x1)
