Backyard Discovery ATLANTIS - Fort Assembly: Step 10; T-Nut Installation Tip

STEP 10 - FORT ASSEMBLY
QTY
PART
NUMBER
DESCRIPTION
8 H100012 BOLT WH 5/16x2
4 H100013 BOLT WH 5/16x2 1/4
4 H100027 LAG SCREW WH 5/16x2
16 H100030 WASHER LOCK EXT 8x19
16 H100074 T-NUT 5/16
012 (x4)
BOLT - 2"
030 (x16)
WASHER - 8x19
074 (x16)
T-NUT - 5/16"
027 (x4)
LAG SCREW - 2"
013 (x4)
BOLT - 2 1/4"
012 (x4)
BOLT - 2"
M9 (x1)
L8 (x1)
M9 (x1)
G1 (x1)
CLUB HOUSE WALL RAIL - W100569
5/8"x4 3/8"x40" (16x112x1016)
L8
(x1)
WALL RAIL - W100581
5/8"x3 3/8"x37 1/2" (16x86x951)
M9
(x2)
SWING BEAM MOUNT - W102365
1"x5 1/4"x37 3/8" (24x134x950)
G1
(x1)
TIP:
INSTALL T-NUTS INTO
BOARDS BEFORE ASSEMBLY
37 3/8 in
[950 mm]
42
