Backyard Discovery ATLANTIS - Fort Assembly: Step 15; Bracket as Guide for Drilling

QTY
PART NUMBER DESCRIPTION
4 H100083 SCREW TAPPING 14x3/4
20 H100088 SCREW PFH 8x1-1/8"
STEP 15 - FORT ASSEMBLY
088 (x20)
SCREW - 1 1/8"
M5 (x4)
N8 (x2)
083 (x4)
SCREW - 14x3/4"
061 (x2)
L BRACKET GREEN 32x51
WALL BOARD - W100577
5/8"x3 3/8"x42" (16x86x1066)
M5
(x4)
WALL BOARD SUPPORT - W100595
5/8"x2 3/8"x6 3/4" (16x60x170)
N8
(x2)
L BRACKET GREEN 32x51
(x2)
A100061
USING BRACKET AS
A GUIDE, DRILL
1/8" (3mm) HOLES.
47
