Backyard Discovery Aurora - Page 26

SWING BEAM
Ǣǻrƻˢ
˟ˢ˟  ʹɮˠʺ
ɟǢËrNJ˚˧ɮˠ˨
˟ˡˠ ʹɮˠʺ
Dŷĵǻ˚ˣˠˀˡ˃
˟˟ˤ ʹɮˠʺ
ŗȕǻDNJNJrĵ˚˦ˀ˧˃
˟ˢˠ ʹɮˠʺ
ɟǢËrNJ˚ˠˡɮˠ˨
˟˦ˣ ʹɮˡʺ
ǻ˚ŗȕǻ˚ˤˀˠ˥˃
˟ˢ˟ ʹɮˡʺ
ɟǢËrNJ˚˧ɮˠ˨
˟ˠˢ ʹɮˡʺ
Dŷĵǻ˚ˡˠˀˣ
˟ˢ˟ ʹɮˡʺ
ɟǢËrNJ˚˧ɮˠ˨
˟ˡ˦ ʹɮˡʺ
ĵµǢNNJrɟ˚ˡ˃
r˦˦ ʹɮˠʺ
ŗµĵrDNJNr
r˦˦ ʹɮˠʺ
ŗµĵrDNJNr
ɟ˦ˠ ʹɮˠʺ
ǢɟÝŗµDrōǢȕƻƻŷNJǻ
Ë˦˨ ʹɮˠʺ
rŗ^ǢȕƻƻŷNJǻ
WASHER LOCK EXT
8x19
(5)
H100030
WASHER LOCK EXT
12x19
(1)
H100031
NUT BARREL WH
5/16x7/8
(1)
H100005
BOLT WH
5/16x2 1/4
(2)
H100013
BOLT WH
5/16x4 1/2
(1)
H100021
LAG SCREW WH
5/16x2
(2)
H100027
SWING BEAM SUPPORT - W4L13292
2"x3 3/8"x44 1/4" (50x86x1123)
W71
(1)
END SUPPORT - W4L13294
1"x3 1/2"x39 1/2" (24x86x1000)
H79
(1)
ANGLE BRACE - W4L13293
1 3/8"x3 3/8"x72 7/8" (36x86x1850)
E77
(2)
T-NUT
5/16
(2)
H100074
26
