FORT ASSEMBLY
Ǣǻrƻ˥
NOTE:
INSTALL FLOOR BEFORE N2 BOARD.
FLOOR BOARD - W4L13225
5/8"x4 3/8"x33 3/4" (16x112x856)
L2
(1)
FLOOR BOARD - W4L13224
5/8"x3 3/8"x36 5/8" (16x86x930)
M4
(5)
FLOOR BOARD - W4L13223
5/8"x4 3/8"x33 3/4" (16x112x856)
L1
(1)
SCREW PFH
8x1 1/2
(43)
H100086
˟˧˥  ʹɮˣˢʺ
ǢNNJrɟ˚ˠˠˀˡ˃
ĵˠ ʹɮˠʺ
ōˣ ʹɮˤʺ
ĵˡ ʹɮˠʺ
SIDE RAIL - W4L13218
5/8"x2 3/8"x36 5/8" (16x60x930)
N2
(1)
WASHER LOCK
EXT
8x19
(2)
H100030
LAG SCREW WH
5/16x2
(2)
H100027
ŗˡ ʹɮˠʺ
˟ˢ˟ ʹɮˡʺ
ɟǢËrNJ˚˧ɮˠ˨
˟ˡ˦ ʹɮˡʺ
ĵµǢNNJrɟ˚ˡ˃
NOTE HOLE LOCATION
33
