Backyard Discovery Aurora - Page 32

FORT ASSEMBLY
Ǣǻrƻˤ
FLOOR SUPPORT - W4L13289
15/16"x1 5/16"x17 1/4" (24x34x438)
T1
(2)
FLOOR RAIL - W4L13221
1"x3 3/8"x24 1/8" (24x86x612)
H3
(1)
"A" REVISION TAG
(1)
A100314
SCREW PFH
8x2 1/2"
(4)
H100090
SCREW PFH
8x1 3/4
(10)
H100089
SCREW PWH
8x5/8
(2)
H100128
˟˨˟  ʹɮˣʺ
ǢNNJrɟ˚ˡˠˀˡ˃
˟˧˨ ʹɮˠ˟ʺ
ǢNNJrɟ˚ˠˢˀˣ˃
ˠˡ˧ ʹɮˡʺ
ǢNNJrɟ˚ˤˀ˧
ˢˠˣ ʹɮˠʺ
˃˃NJrəÝǢÝŷŗǻµ
(APPROXIMATE LOCATION)
ǻˠ ʹɮˡʺ
Ëˢ ʹɮˠʺ
32
